Product Detail:

The seires of product utilize oxygen from internal oxygen generator as gas source and high concentration ozone is generated by ozone generaion part.The product has integrated oil-free air compressor and filtering system thus ozone is produced  by just power on it.The products use heat-resistant HQG non-glass structure discharge unit(BNP patent),the structure is extremely stable,has long lifespan and high discharge efficiency and not easily damaged in case of back flow water.

Product Features:

This seires of products use American zeolite molecular sieve adsorbent,separating oxygen from nitrogen in the air using pressure swing adsorption(PSA) pricinple,filtering other substances in the air to obtain a high concentation oxygen in line with medical oxygen standards.

Multi-point malfuction monitoring,main board temperature detection,high voltage transformer temperature detection,cooling water temperature detection,PSA input air temperature detection,backflow water detection.The equipment stops opereating and the corresponding fault indicator on the control panel lights up when a fault is detected.

Standard 4~20mA signal control.

The whole gas circuits work in low pressure which makes it safe and reliable.

Air source input with no additive required and lower power consumption which ensures lower total cost.

Two oxygen generation units work alternatively and automatically.

1.Water-cooling.

2.Intergrating oxygen generating and ozone generating.

3.Adapt pressure swing adsorption(PSA) method and American zeolite molecular sieve to separate oxygen from nitrogen and filter harmful substances in the air to obtain high concentration oxygen in line with medical oxygen standards.

4.The machine contains oil free air compressor.

5.Adjustable ozone output.Standard 4~20mA signal access port,allowing remote control by different types of ozone measureing devices.

6.Key points monitoring including main board temperature detection,line output transformer temperature detection,cooling water temperature detection,back flow water  detection of the corona discharge tube.

7.All gas circuits work in low pressure,safe and reliable.
